2025 TREK MARLIN 6 GEN 3 - MIAMI GREEN TO DARK AQUATIC FADE
Product image 1
Product image 2
Product image 3
Regular price
$999.99
Sale price
$1,199.99
- *Frame
-
Size: XS
Alpha Silver Aluminium, curved top tube, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkewSize: S , M , ML , L , XL , XXL
Alpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew - *Fork
-
Size: XS , S
RockShox Judy, coil spring, preload, TurnKey lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 100 mm travelSize: M , ML , L , XL , XXL
RockShox Judy, coil spring, preload, TurnKey lockout, 46 mm offset for 29" wheel, 100 mm QR, 100 mm travel
- Hub front
-
Formula DC-20, alloy, 6-bolt, 100 mm
- Hub rear
-
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm
- Skewer rear
- Rim
-
Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve
- *Tyre
-
Size: XS , S
Maxxis IKON, tubeless ready, EXO casing, folding bead, 60 tpi, 27.5x2.35''Size: XS , S
Maxxis Ardent Race, tubeless ready, EXO casing, folding bead, 60 tpi, 27.5x2.35"Size: M , ML , L , XL
Maxxis IKON, tubeless ready, EXO casing, folding bead, 60 tpi, 29x2.35''Size: M , ML , L , XL , XXL
Maxxis Ardent Race, tubeless ready, EXO casing, folding bead, 60 tpi, 29x2.35" - Max tyre size
- Frame: 29x2.40" (XXS: 26x2.40", XS & S: 27.5x2.40"), Fork: See manufacturer
- Shifter
-
Shimano U6000, 10-speed
- Rear derailleur
-
Shimano CUES U6000 GS
- *Crank
-
Size: XS
FSA Alpha Drive, 30T, 160 mm lengthSize: S , M , ML
FSA Alpha Drive, 30T, 170 mm lengthSize: L , XL , XXL
FSA Alpha Drive, 30T, 175 mm length - Bottom bracket
-
FSA, 73 mm, threaded cartridge, 122.5 mm spindle
- Cassette
-
Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed
- Chain
-
Shimano LG500
- Pedal
- Max. chainring size
- 1x: See FAQ, 2x: 36T, 3x: 42T
- Saddle
- *Seatpost
-
Size: XS , S , M
Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm lengthSize: ML , L , XL , XXL
Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length - *Handlebar
-
Size: XS
Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm widthSize: S
Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm widthSize: M , ML , L , XL , XXL
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width - Grips
- *Stem
-
Size: XS , S
Bontrager Comp, 31.8 mm, 7-degree, 35 mm lengthSize: M , ML , L
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm lengthSize: XXL
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length - Head set
-
Semi-integrated, 1-1/8"
- Brake rotor
- *Brake Set
- Rotor size
- Max brake rotor sizes - Frame: 180mm (XXS: 160mm), Fork: see fork manufacturer
- Weight
- M - 14.50 kg / 31.97 lbs (with tubes)
- Weight limit
- This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
